Dai-ichi Seiko I-PEX CABLINE®-CA connectors
DisplayPort(2.7Gbps to 5.4Gbps) with optimized design of contact and march internal GND points.
0.4mm Pitch Horizontal type Micro Coax connector.
Mating Height : 1.1mm.
“W-Point” contact with High mating reliability.
Anti-reverse mating design.
Locking bar prevents accidental unmating (Option).
| Pitch |
0.4 |
| Pin Counts |
12, 20, 30, 40, 50, 60 |
| Mating Parts |
Cable |
Cable |
Cable |
PCB |
Cable |
| Plug |
Plug |
Plug |
Rece |
Plug for Cable assembly |
| Housing |
Shell A |
Pull Bar |
|
|
| Prefix Number |
20634 |
2764 |
2766 |
20525 |
20633 |
| Parts Number |
20634-1**T-02 |
2764-0***-*** |
2766-0**1 |
20525-***E-** |
20633-2**T-01S |
Recommended
P/N |
20634-112T-02
20634-120T-02
20634-130T-02
20634-140T-02
20634-150T-02
20634-160T-02 |
2764-0121-002
2764-0201-002
2764-0301-002
2764-0401-002
2764-0501
2764-0601-002 |
2766-0121
2766-0201
2766-0301
2766-0401
2766-0501
2766-0601 |
20525-012E-02
20525-020E-02
20525-030E-02
20525-040E-02
20525-050E-02
20525-060E-02 |
20633-212T-01S
20633-220T-01S
20633-230T-01S
20633-240T-01S
20633-250T-01S
20633-260T-01S |
| Note |
|
|
|
|
Set parts number of Housing, Shell A, (Pull Bar)
|
